SL310TU-36P
SL315TU-36P
SL320TU-36P
SL325TU-36P
SL330TU-36P
SL335TU-36P
Modules sorted by current optimizing system power generation.
High efficiency.
Stable power.
Low carbon emission.
Excellent weather resistance.
| Maximum Power (W) | 310 | 315 | 320 | 325 | 330 | 335 |
| Optimum Power Voltage (Vmp) | 37.76 | 37.94 | 38.12 | 38.30 | 38.48 | 38.67 |
| Optimum Operating Current (Imp) | 8.21 | 8.30 | 8.39 | 8.49 | 8.58 | 8.66 |
| Open Circuit Voltage (Voc) | 44.81 | 44.98 | 45.15 | 45.32 | 45.49 | 45.66 |
| Short Circuit Current (Isc) | 8.79 | 8.88 | 8.98 | 9.08 | 9.18 | 9.27 |
| Cell Efficiency (%) | 15.98 | 16.23 | 16.49 | 16.75 | 17.01 | 17.26 |
| Tolerance Wattage (%) | 15.98 | |||||
| NOCT | 45°C +/-2°C | |||||
| Temperature Coefficients of Isc (%) °C | +0.05 |
| Temperature Coefficients of Voc (%) °C | -0.32 |
| Temperature Coefficients of Pm (%) °C | -0.41 |
| Solar Cell | 156*156 Poly |
| Number of Cells (pcs) | 6*12 |
| Size of Module (mm) | 1956*992*40 |
| Surface Maximum Load Capacity | 2400-5400Pa |
| Allowable Hail Load | 23m/s, 7.53g |
| Weight Per Piece (KG) | 22.5 |
| Junction Box Type | Pass the TUV Certificate |
| Bypass Diode Rating (A) | 30 |
| Cable & Connector Type | Pass the TUV Certificate |
| Frame (Material Corners, etc.) | 40# |
| Tempeature Range | -40°C to +85°C |
| FF (%) | 70-79% |
| Standard Test Conditions | AM1.5 1000W/m² 25°C |
